Anti-drone equipment
This Anti-drone equipment is against the great risk in the civilian and military field . It offers the fast speed of drone jamming function when it is applied to the customer specific need such as the portable drone jammer, fixed drone jammer, movable vehicle drone jammer and the drone detector combination. The signal jammer moduel is of high exactness and accuracy. TeXin is the professional supplier for the drone signal jammer, anti drone jammer module, phone wifi gps signal jammer, antenna and etc.
Send Inquiry
Product Description
Anti-drone equipment
TeXin is dedicated to the anit drone signal jammer module. The signal jammer module is totally customized according to the customer specific need. When customer requires it, we exactly do it according to the detail frequency and output power from 20MHz to 6.2GHz, and output power be 5W to 200W.This anti drone module can be 5W 10W 20W 30W 40W 50W 100W. 2.4G can be 200W.
Anti Drone Module Specification
|
30W 40W 50W Version |
||||
|
No. |
Item |
Data |
Unit |
Notes |
|
1 |
Frequency |
Customized |
MHZ |
|
|
2 |
Work Temperature |
-10~+75 |
℃ |
|
|
3 |
Output Power |
30 |
W |
|
|
4 |
Work Voltage |
DC24 |
V |
|
|
5 |
Max Gain |
45±1.5 |
dB |
|
|
6 |
Flatness |
±3 |
dB |
|
|
7 |
Max Current |
2.2 |
A |
|
|
8 |
Output VSWR |
≤1.5 |
|
|
|
9 |
Output Connector |
N/F 50Ω |
|
customized |
|
10 |
Power Amplifier Efficiency |
41.6 |
|
when Max Output |
|
11 |
Switch Control |
high low |
V |
0V off /0.6 on |
|
12 |
Standing Wave Protection |
OK |
|
|
|
13 |
Temperature Protection |
75° |
℃ |
|
|
14 |
Size |
137*58*18 |
mm |
|
|
15 |
Weight |
0.22 |
Kg |
|
